DOBOT CR3AS – Compact Collaborative Robot with Advanced Safety 🤖



🔹 Product Description:
DOBOT CR3AS is an advanced collaborative robot with a payload of 3 kg and a reach of 620 mm, designed specifically for precise and dynamic applications. This model features an advanced safety system (AS – Advanced Safety) and SafeSkin technology, which provides the highest level of protection when working with people. SafeSkin enables contactless obstacle detection and automatic stopping of the robot before a collision, which increases the safety and efficiency of operations.



🔹 Key features:
Payload capacity 3 kg – ideal for precise operations
Reach 620 mm – perfect for small and medium-sized workstations
Accuracy ±0.02 mm – ensures the highest accuracy
Advanced safety – modern collision sensors and collaborative modes
SafeSkin technologycontactless obstacle detection, greater operator protection
Lightweight and compact design – easy to assemble and Integration
Energy Efficient – Optimized Motor Operation





DOBOT CRA SafeSkin Series

Equipped with SafeSkin for greater safety and increased efficiency. The CRAS Series is an upgraded version of the CRA Series. It has the same features and performance as the CRA Series, and has been further enhanced with the addition of SafeSkin for pre-collision detection, achieving greater safety and more efficient collaboration.



DOBOT CR3AS

SKU: 1200000218-7
€14,500.00Price
Excluding Sales Tax
Quantity
  • [tabledata]
    Weight | 16.5 kg
    Max load capacity | 3 kg
    Working radius | 620 mm
    Max range | 795 mm
    Rated voltage | 48V DC
    Max linear speed | 2 m/s
    Joint range [rowspan=6] | J1 | ±360°
    | J2 | ±360°
    | J3 | ±155°
    | J4 | ±360°
    | J5 | ±360°
    | J6 | ±360°
    Max joint speed [rowspan=2] | J1/J2 | 180° /s
    | J3/J4/J5/J6 | 223° /s
    End Effector I/O Interface [rowspan=2] | DI/DO/AI | 2
    | AO | 0
    Communication Interface | Communication | RS485
    I/O Controller [rowspan=4] | DI | 16
    | DO/DI | 16
    | AI/AO | 2
    | ABZ Incremental Encoder | 1
    Repeatability | ±0.02 mm
    Communication | TCP/IP, Modbus, Wi-Fi
    IP Rating | IP54
    Temperature | 0° ~ 50° C
    Power | 120 W
    Materials | Aluminum alloy, ABS plastic
    [/tabledata]


  • [tabledata]
    Model | SafeSkin
    Detection Type | Proximity and Contact
    Target Detection | Human bodies, metals, liquids, etc. (less effective on non-conductive objects)
    Installation Locations | J4, J5, J6 Recommended
    Effective Detection Range | 5 to 15 cm (varies depending on installation location)
    Detection Cycle Time | 0.01 s
    Emergency Stop Execution Time | 0.1 s
    [/tabledata]
